Contra Mixer

CREAM, OINTMENT, GEL, SHAMPOO, TOOTHPASTE


The principle of contra-rotation of blades is employed in the Contra Mixer to enable simultaneous beating and scraping operations. It is primarily used for the manufacturing of toothpaste, creams, cosmetics, and other viscous products.

A series of paddle-type blades with specially designed shapes is included in the mixing assembly, allowing the material to be moved back toward the center of the container. These blades are mounted on a central shaft, which is enclosed by a hollow shaft. Additional blades are welded onto the hollow shaft. Both sets of blades are intermeshed and are rotated in opposite directions—clockwise and anti-clockwise.

The mixer is designed to withstand high vacuum pressure that may be applied during the process, ensuring optimal mixing results.

Contra Mixers with capacities ranging from 50 liters to 5,000 liters are manufactured by Varcogroup to serve a wide range of industrial applications.

Product Features

1
Dual Contra-Rotating Blades – Ensures uniform mixing through simultaneous beating and scraping.
2
Vacuum-Compatible Design – Allows high vacuum application for air-free, homogeneous mixing.
3
Paddle-Type Intermeshing Blades – Designed for efficient movement of viscous materials toward the center.
4
Hollow Shaft Construction – Enables compact integration of dual-blade systems for optimal performance.
5
Versatile Application – Ideal for creams, gels, ointments, shampoos, and toothpaste production.
6
Robust Build Quality – Engineered to handle high-viscosity materials with consistent results.
7
Wide Capacity Range – Available from 50 liters to 5,000 liters, suiting both small and large-scale operations.
9
Customizable Configuration – Can be tailored to specific process requirements.
8
All contact parts made of SS316.
9
SCADA option is available with 21CFR PART 11 for system security.
10
Fully Automated PLC-based system with four levels of security Passwords.
11
LOBE PUMP for transfer of the final product
12
High shear Homogenizer to give less than 10 microns’ globule size in products.
